Electric Forklift

SafeView@360

The CLARK SafeView@360 is a 360° camera system, that consists of four digital cameras, which give a complete 360-degree view to the driver.  In this way, the driver has a excellent image of his surrounding, which increases safety during operation.

By using digital cameras, it is also possible to generate a view from the bird´s eye perspective. The four individual cameras are used to form a common image in real-time. Especially the fork tips and the counterweight, these are precisely integrated into the seamless image displayed.

Thanks to this perfect all-round visibility the application in narrow or unclear areas can be done more safely and quickly.

Electric Forklift

Make use of the advantages of CLARKs Li-Ion batteries

• Powerful lithium-ion battery with 80V 560 Ah
• Short charging time thanks to a 80 Volt (120 A) charger
• Double service life and maintenance-free batteries
• Opportunity charging is possible at any time
• No battery change required
• Various charging points can be installed directly where the unit is used, as no ventilated charging room is required

Electric Forklift

CLARK Lithium-ion chargers for counterbalance trucks

The chargers supplied by CLARK have an extremely stable housing construction with wall bracket for easy mounting. An LED display informs the operator about the battery’s charge status. The connection to the charger is made via a charging cable, which is within easy reach on the vehicle battery.

Intelligent Battery Management System (BMS)

The battery management system in the CLARK Li-Ion batteries communicates with the vehicle and the charger via a CAN bus interface. It informs the operator via display about the state of charge and the remaining runtime. In addition, the intelligent BMS ensures that the Li-Ion battery is neither deep discharged nor overcharged and thus contributes to a long battery life and efficient use of the industrial truck.

Electric Forklift

CLARK Lithium-Ion Power: Costs Down – Power On

Modern lithium-ion technology in perfect combination with cost-efficient trucks and a wide range of additional optional equipment to customize the forklifts is only available from CLARK! It pays to switch to a counterbalance truck with a modern clean energy source. Thanks to ultra-fast charging times and zero maintenance, the lithium-ion forklifts can be used almost without a break. The power of the battery is always fully available, as lithium-ion batteries do not show any signs of fatigue. In addition, the service life of lithium-ion batteries is significantly longer than that of the lead-acid battery.

Electric Forklift

Lithium iron phosphate technology (LiFePO4)

CLARK batteries are based on the safe lithium-ion phosphate technology (LiFePO4). With LiFePO4 batteries, no oxygen is released during the chemical reaction within the cells. This means that there is no risk of spontaneous combustion or explosion of the battery. The battery consequently is very safe. Vehicles with lithium-ion phosphate batteries perform efficiently even in winter at low ambient temperatures and in summer.

The service life of the lithium-ion battery is at least twice as long as the lead-acid battery, up to 2500 charging cycles. Depending on the application, this can be potentially doubled. In light/medium applications, the battery can be used for in excess of 10 years.

Electric Forklift

Intermediate charging

The Li-Ion battery can be opportunity charged without any problems, for example during breaks, without loss of capacity or damage to the battery. The battery cover does not have to be opened for this. The driver can connect the plug of the charger to the side of the Li-Ion battery. After only a short time, 50 % of the charge level is available again. Lead-acid batteries lose part of their capacity when not in use, during intermediate charging or when charging is interrupted. The complete charging process for counterbalance trucks with Li-Ion batteries is completed after approx. 3.5 hours, whereas it takes significantly longer for vehicles with lead-acid batteries.
